USBee ax pro to USB Blaster reprogramming Original lsusb output, for the device that is not recognized by quartus prime Bus 001 Device 002: ID 08a9:0014 CWAV Inc. USBee AX-Pro Its was sold as USB blaster clone done with a cypress chip, (CY7C68013A) with and eeprom 24C08N. But it was never recognized as a USB …
Continuar a ler “bad USBee ax pro USB blaster cypress based clone reprograming”
This document is about geting the Gerber & Excellon Files needed to use in flatcam to generate the gcode files formilling PCB milling in 3018 CNC with Candle or GRBL-control. We should use the LabeE.dru file that is available on the link bellow. LabE – eagle – design rules (dru) and library (lbr) These design rules …
Software (linux) Candle https://github.com/Denvi/Candle https://github.com/Denvi/Candle/releases/tag/v1.0 (old grbl firmware) Install candle linux ubuntu 20.04 ORIGINAL —————————————- Z-probe commands G91G21; G38.2Z-30F100; G0Z1; G38.2Z-1F10 G91G21G38.2Z-50F100; G92 Z0; G0Z5M30 G38.2 Z-1 F1; G92 Z0 FlatCam http://flatcam.org/ git clone https://bitbucket.org/jpcgt/flatcam Install Flatcam linux ubuntu 20.04 set_sys excellon_zeros T http://flatcam.org/manual/index.html http://flatcam.org/tutorial/selective https://altrish.co.uk/wp-content/uploads/2021/02/flatcam-and-milling-pcbs-2021.pdf ( Local copy flatcam-and-milling-pcbs-2021 ) FlatCAM pratica tutorial: introduction, installation and …
Install Candle (old grlb-control) linux ubuntu 20.04 https://github.com/Denvi/Candle https://github.com/Denvi/Candle/releases/tag/v1.0 (old grbl) Install Candle Ubuntu Focal 20.04 We cant run candle in ubuntu 64 bits. It gives an ELF error, so we need to replace the executable. This instructions ar for the version 1.0 as my CNC 3018 have the old firmware. For the last one, …
DDS Function Signal Generator Gerador de funções, gerador de ondas, gerador de sinais. Necessita de uma fonte simétrica de +/-12V para o sinal, e 5V para o funcionamento Especificações: Alimentação: +5V / +12V / GND/ -12V Sinais de alta frequência: 1, 2, 4, 8MHz Ecrã: 2 * 16 LCD Tamanho do ecrã: 6.5cm * 1.5cm …
https://w5nor.org/wp-content/uploads/2018/02/Pixie-II-v5-for-caarc.pdf https://w5nor.org/wp-content/uploads/2018/02/NCRC_PixieOperation.pdf https://w5nor.org/wp-content/uploads/2018/02/SKU420968-S-Pixie-User-Manual.pdf http://www.oz1bii.dk/documents/Pixie-Transceiver-OZ.pdf Pixie 1/2 Watt CW 40 Meter Transceiver Kit https://w5nor.org/wp-content/uploads/2018/02/2018-02-CQ-Pixie-Transceivers-Construction-Color.pdf
Imax B6 LiPro Batery Balance Charger Manual: imax_b6_eng_man
Medidor digital de carga de baterias: Lipo, LiFe, Li-Ion, NiMh e NiCd Folheto com detalhes
Multifunctional LCD GM328A Component Tester Multi-functional transistor tester for automatic detection of NPN and PNP transistors, FET, diodes, dual diode, thyristor, SCR, automatic identification of the transistor pinout. It also can be used as square signal and PWM signal generator. Features Digital LCD display for easy readings, can display measured data and graphics. Rotary …
Fonte de tensão de precisão Referência para multímetros e voltímetros. LM399 V1 – 2.5 V = 2.51846 V v2 – 5.0 V = 5.03670 V V3 – 7.5 V = 7.55460 V V4 – 10.0 V = 10.07489 V A foto principal é a da minha fonte de precisão (LM339) As fotos abaixo são meramente …
Continuar a ler “Fonte de tensão de precisão (referência) – LM399”
